Womala Turbochargerr C2D40425 for Jaguar XJ XF XE Range

Product Overview

The Supercharger Repair Kit C2D40425 (also referenced as C2D53104) is a Genuine OE-grade service component engineered for the 3.0L V6 supercharged petrol engine (AJ126) in select for Jaguar and for Land Rover vehicles. This kit contains the critical internal components required to address mechanical noise and play issues in the supercharger nose assembly, primarily the torsional isolator and spring support shaft.C2D53104 is the current replacement part number, superseding C2D40425.

⚠️ Important: This is a supercharger repair kit — not a turbocharger repair kit. It is specifically for the 3.0L V6 supercharged petrol engine (AJ126 / 3.0 SCV6). It is not compatible with 5.0L V8 supercharged, diesel, or 2.0L variants.

Key Features

• Torsional isolator and spring support shaft – replaces the worn internal coupling that causes excessive backlash in the supercharger drive

• Addresses supercharger clattering/knock/rattle noise – a documented issue on the 3.0L V6 SC engine

• OE-grade quality – available as Genuine Jaguar, INA (Schaeffler), and other quality alternatives

• Cost-effective repair – restores supercharger function without replacing the complete unit

• May be installed with intake manifold gasket – LR041681 is commonly replaced during this service

OE Cross-Reference

💡 Supersession Note: C2D53104 is the current replacement for C2D40425. LR059341 and LR088538 are Land Rover equivalent references for the same kit.

Technical Specifications

Vehicle Fitment

⚠️ Important: This repair kit is confirmed for the 3.0L V6 supercharged petrol engine (AJ126) in the models listed above. Confirm your engine type and VIN before ordering.

Signs of Failure

• Clattering / knock / rattle noise – from the supercharger, especially at idle or under load

• Significant free play when turning the pulley – before the rotors start to turn

• Excessive backlash in the supercharger drive – worn torsional isolator or spring support shaft

💡 Diagnostic Note: If there is a clunk/knock noise from the supercharger or significant free play when turning the pulley before the rotors start to turn, install this supercharger spring isolator kit.

Critical – Verify Your VIN Before Ordering

Supercharger repair kits are VIN- and engine-specific. This kit is for the 3.0L V6 supercharged engine only — confirm your engine type before ordering. Provide your VIN – our team confirms exact compatibility before dispatch. We cannot accept returns for misordered parts without VIN verification.

💡 Installation Tip: Professional installation required — supercharger removal is necessary to access the isolator. Refer to Workshop Manual Section 303-12 for the repair procedure. It is recommended to replace the intake manifold gasket (LR041681) during installation. A core exchange surcharge may apply on remanufactured units.
