Womala Engine Oil Cooler Gaskets LR061969 for Land Rover Discovery Range Rover Sport

Product Overview

The Oil Filter Housing Assembly LR061969 is a Genuine OE-grade engine lubrication component engineered for 3.0L V6 diesel engines (306DT / TDV6 / SDV6) in select for Land Rover and for Jaguar vehicles. This complete module integrates the oil filter housing, oil cooler, filter element, and seals into a single assembly, responsible for filtering engine oil and regulating its temperature through coolant-based heat exchange. LR124259 is the current replacement part, superseding LR061969.

Key Features

• Complete module assembly – includes oil filter housing, oil cooler, filter element, and seals

• Integrated oil cooler – water-cooled heat exchanger regulates oil temperature

• OE-grade quality – available as Genuine Land Rover and quality alternatives (Metzger, Vemo, Nissens, Mahle)

• Direct-fit replacement – matches factory mounting points and connections

• For 3.0L V6 diesel engines – 306DT / TDV6 / SDV6 engine family

OE Cross-Reference

Additional references: 1103.S9, 1103S9

💡 Note: LR061969 and LR124259 are interchangeable part numbers for the same complete oil filter housing module with integrated oil cooler.

Technical Specifications

Vehicle Fitment

Engine details (verify with VIN):

• 3.0L V6 Diesel 24V DOHC TC (306DT / TDV6 / SDV6)

• Power variants: 211–306 PS (155–225 kW)

⚠️ Important: This assembly is specifically for 3.0L V6 diesel engines — not for 2.0L diesel, 4.4L V8 diesel, or petrol variants. For 5.0L V8 and 3.0L V6 petrol engines, a different oil filter assembly (LR010722) is required.

Signs of Failure

• Oil leaks – visible oil around the filter housing or cooler area

• Coolant leaks – internal failure allowing coolant to mix with oil

• Engine overheating – reduced oil cooling efficiency

• Cracking or distortion – visible damage to the housing body

• Oil pressure warning – restricted oil flow due to internal blockage

💡 Known Issue: JLR engineering investigations have found that oil filter housings on certain Ingenium engine variants may crack, causing a possible high-pressure oil leak. The oil filter housing is a common failure point — cracking and leaking are the primary symptoms.

Critical – Verify Your VIN Before Ordering

Oil filter housing assemblies are VIN-, engine-, and model-year-specific. Confirm your engine type (3.0L V6 diesel vs. petrol) before ordering — petrol variants use a different assembly (LR010722). Provide your VIN – our team confirms exact compatibility before dispatch. We cannot accept returns for misordered parts without VIN verification.

💡 Installation Tip: Professional installation recommended. When replacing the oil filter housing assembly, inspect all oil and coolant lines for wear. Replace the oil filter element and seals as part of the installation. Refill with OEM-specified oil and coolant at the correct mixture ratios.

Why Choose Us

Contact us for bulk orders or VIN‑checked quotes.

Specifications subject to change; images for reference only.Aftermarket replacement – not affiliated with Jaguar Land Rover.
